The Aidite AMD-500E is a versatile five-axis dental milling machine designed for precise CAD/CAM processing of various materials. Its user-friendly interface, dust-proof design, and efficient material utilization features make it a valuable asset for dental labs. The machine’s ability to perform vertical milling and its smart alert system further enhance its accuracy and reliability.
Machine Specifications
| Parameter | Description |
|---|---|
| Platform | Aviation cast aluminum |
| Dimensions and weight | 520×650×720(mm) |
| Weight | 120Kg |
| Processing methods | Dry milling |
| Number of tools | 8 |
| Dust-proof | Integrated silicone |
| Fixture Type | Secondary fixture/98 disk (Optional)/Block type (Optional) |
| Processing material thickness | 10-35mm |
| Processing material | Zirconia, PMMA, WAX, PEEK, HPP, Soft Metal |
| CAM software | Open CAM System |
| 90° buccal side machining | √ |
| Motor | Servo motor |
| Air Pressure | ≥6Bar |
| Power supply processing base time | 10-30mm |
| Machining time | Full Crown <15min, Bridge <3h |
Spinde
Air Cooling
Max:60000RPM
500W
4mm Chuck
Machining angle
A Axis: +135°,
-30° B Axis:360°
